- Brand : Lenovo
- Product family : ThinkVision
- Product name : 27 3D
- Product code : 63F1UAR3WL
- Category : Computer Monitors ✚
- Data-sheet quality : created/standardized by Icecat
- Product views : 67585
- Info modified on : 25 Jul 2025 18:31:56
- EU Energy Label 0.1MB Product Brochure/Datasheet (1.3 MB) EU data-sheet (0.1 MB)
Embed the product datasheet into your content
This browser does not support the video element.
| Display | |
|---|---|
| Display diagonal | 68,6 cm (27") |
| Display resolution | 3840 x 2160 pixels |
| HD type | 4K Ultra HD |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Panel type | IPS |
| LED backlight | |
| Backlight type | W-LED |
| Touchscreen | |
| Display brightness (typical) | 310 cd/m² |
| Response time | 6 ms |
| Anti-glare screen | |
| Screen shape | Flat |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 3000000:1 |
| Maximum refresh rate | 60 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 16.7 million colours |
| Response time (fast) | 4 ms |
| Pixel pitch | 0,155 x 0,155 mm |
| Pixel density | 163 ppi |
| Viewable size, horizontal | 59,7 cm |
| Viewable size, vertical | 33,6 cm |
| High Dynamic Range (HDR) supported | |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10) |
| Colour depth | 8 bit |
| Colour gamut standard | DCI-P3 |
| Colour gamut | 99% |
| sRGB coverage (typical) | 100% |
| Adobe RGB coverage | 99% |
| BT.2020 coverage | 83% |
| Multimedia | |
|---|---|
| Number of speakers | 2 |
| RMS rated power | 10 W |
| Built-in speaker(s) | |
| Built-in microphone | |
| Built-in camera | |
| Design | |
|---|---|
| Product colour | Black |
| Colour name | Raven Black |
| Detachable stand | |
| Feet colour | Black |
| Ports & interfaces | |
|---|---|
| Built-in USB hub | |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type | USB Type-C |
| Number of upstream ports | 1 |
| Number of USB Type-C upstream ports quantity | 1 |
| USB Type-A downstream ports quantity | 4 |
| USB Type-C downstream ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | |
| USB Power Delivery | |
| USB Power Delivery up to | 100 W |
| HDMI | |
| HDMI ports quantity | 2 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Audio output | |
| Network | |
|---|---|
| Ethernet LAN | |
| Ergonomics | |
|---|---|
| VESA mounting | |
| Panel mounting interface | 100 x 100 mm |
| Cable management | |
| Cable lock slot | |
| Cable lock slot type | Kensington |
| Height adjustment | |
| Adjustable height (max) | 15,5 cm |
| Pivot | |
| Pivot angle | -90 - 90° |
| Swivelling | |
| Swivel angle range | -45 - 45° |
| Tilt adjustment | |
| Tilt angle range | -5 - 23,5° |
| Power | |
|---|---|
| Energy efficiency class (SDR) | G |
| Energy efficiency class (HDR) | G |
| Energy consumption (SDR) per 1000 hours | 41 kWh |
| Energy consumption (HDR) per 1000 hours | 53 kWh |
| Power consumption (typical) | 43,8 W |
| Power consumption (standby) | 0,5 W |
| Power consumption (max) | 246 W |
| Power consumption (off) | 0,5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | Internal |
| Energy efficiency scale | A to G |
| European Product Registry for Energy Labelling (EPREL) code | 1780143 |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 8 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
|---|---|
| Width (with stand) | 614,8 mm |
| Depth (with stand) | 222,7 mm |
| Height (with stand) | 568 mm |
| Weight (with stand) | 8,9 kg |
| Width (without stand) | 614,8 mm |
| Depth (without stand) | 72,3 mm |
| Height (without stand) | 390 mm |
| Weight (without stand) | 6,6 kg |
| Bezel width (side) | 8 mm |
| Bezel width (top) | 8 mm |
| Bezel width (bottom) | 4,43 cm |
| Packaging data | |
|---|---|
| Package width | 720 mm |
| Package depth | 165 mm |
| Package height | 520 mm |
| Package weight | 12,4 kg |
| Package type | Box |
| Packaging content | |
|---|---|
| Stand included | |
| Cables included | AC, DisplayPort, HDMI, USB Type-A to USB Type-C, USB Type-C |
| Quick start guide | |
| DisplayPort cable length | 1,8 m |
| HDMI cable length | 1,8 m |
| Power cable length | 1,8 m |
| Other features | |
|---|---|
| Compatible operating systems | Windows 11 Windows 10 |
| Certification | EU Energy Label Exempt (G-class) RoHS (2011/65/EU) TÜV Rheinland® Eye Comfort Certification |
