Lenovo ThinkCentre Tiny-In-One 24 Gen 5 LED display 23.8" 1920 x 1080 pixels Full HD Touchscreen Black

Edit this data-sheet
Search similar products
More>>> <<<Less
Report mistake
Reasons to buy
  • Tiny Packages that pack a punch
    The TIO 24 Gen 5 is a modular device that supports Lenovo’s range of ThinkCentre and ThinkStation Tiny Computers from 4th Gen. You can easily and quickly attach the Tiny to the monitor and secure them in a dedicated slot on the monitor’s back, offering a clutterfree desk. An unchanged installation process ensures that you have a consistent and smooth experience when attaching Tiny PCs to the monitor. Connect multiple different devices such as laptops, towers, or notebooks using the available HDMI or DP ports. Easily secure both your TIO monitor and Tiny Computer with the Kensington lock for additional security.
  • Remote meetings at its core
    The TIO 24 Gen 5 gives you plug-and-play functionality with Lenovo’s Tiny PCs. A 1080p RGB webcam captures you accurately and two built-in 3W speakers help you listen to your colleagues clearly during meetings. Dedicated VoIP buttons make attending your meetings easier than ever. The menu Joystick allows you to tweak your screen’s settings easily. A dedicated privacy shutter allows you to cover the camera for privacy once a meeting ends. The Smart Traffic Light indicator shows the status of an ongoing meeting to avoid potential disruptions.
  • Your partner as well as nature’s
    Experience clear and sharp detail, and a wide field of view on the monitor’s 23.8-inch FHD In-Plane Switching panel that supports a 99% sRGB color gamut. During long hours of exposure, the Eyesafe 2.0 certified technology and Natural Low Blue Light technology reduces harmful blue light without any color distortion. The TIO 24 Gen 5 also eases your physical comfort with options to lift and lower its height to match your seating position. The monitor is packaged in recycled paper and comes with the option to select a CO2 offset service, which allows you to do your bit for the environment.
Specs
Display
Display diagonal 23.8"
Display resolution 1920 x 1080 pixels
HD type Full HD
Native aspect ratio 16:9
Display technology LED
Panel type IPS
LED backlight
Backlight type W-LED
Touchscreen
Touchscreen technology Capacitive
Touch technology Multi-touch
Display brightness (typical) 250 cd/m²
Response time 6 ms
Anti-glare screen
Screen shape Flat
Contrast ratio (typical) 1000:1
Contrast ratio (dynamic) 3000000:1
Maximum refresh rate 60 Hz
Viewing angle, horizontal 178°
Viewing angle, vertical 178°
Display number of colors 16.7 million colors
Response time (fast) 4 ms
Pixel pitch 0.0108 x 0.0108" (0.275 x 0.275 mm)
Pixel density 93 ppi
Viewable size, horizontal 20.7" (52.7 cm)
Viewable size, vertical 11.7" (29.6 cm)
Color depth 8 bit
Colour gamut standard sRGB
Color gamut 99%
sRGB coverage (typical) 99%
Performance
Low Blue Light technology
Multimedia
Number of speakers 2
RMS rated power 6 W
Built-in speaker(s)
Built-in microphone
Built-in camera
Design
Product color Black
Color name Raven Black
Detachable stand
Feet color Black, Red
Ports & interfaces
Built-in USB hub
USB hub version 3.2 Gen 1 (3.1 Gen 1)
USB upstream port type USB Type-B
Number of upstream ports 1
Number of USB Type-B upstream ports quantity 1
USB Type-A downstream ports quantity 1
USB Type-C DisplayPort Alternate Mode
HDMI
HDMI ports quantity 1
HDMI version 1.4
DisplayPorts quantity 1

Ports & interfaces
DisplayPort version 1.2
Built-in KVM switch
Network
Ethernet LAN
Ergonomics
VESA mounting
Panel mounting interface 100 x 100 mm
Cable management
Cable lock slot
Cable lock slot type Kensington
Height adjustment
Adjustable height (max) 6.1" (15.5 cm)
Pivot
Pivot angle -5 - 90°
Swiveling
Swivel angle range -45 - 45°
Tilt adjustment
Tilt angle range -5 - 23.5°
On Screen Display (OSD)
Power
Power consumption (typical) 14 W
Power consumption (standby) 0.5 W
Power consumption (max) 34 W
Power consumption (off) 0.5 W
AC input voltage 100 - 240 V
Power supply type External
Energy efficiency scale A to G
Weight & dimensions
Width (with stand) 21.3" (539.8 mm)
Depth (with stand) 8.17" (207.6 mm)
Height (with stand) 21.2" (539.6 mm)
Weight (with stand) 13.9 lbs (6.3 kg)
Width (without stand) 21.3" (539.8 mm)
Depth (without stand) 2.87" (72.8 mm)
Height (without stand) 14.5" (367.6 mm)
Weight (without stand) 8.82 lbs (4 kg)
Bezel width (side) 0.0787" (2 mm)
Bezel width (top) 0.0787" (2 mm)
Bezel width (bottom) 1.81" (4.6 cm)
Packaging data
Package width 24.4" (620 mm)
Package depth 7.36" (187 mm)
Package height 16.5" (420 mm)
Package weight 21.6 lbs (9.8 kg)
Packaging content
Stand included
Cables included AC
Power adapter included
Quick start guide
Power cable length 39.4" (1 m)
Other features
Compatible operating systems Windows 10 Windows 11
Certification EPEAT Gold Registered EU Energy Label (D-class) ENERGY STAR Certified TCO Certified 9.0 TCO edge 2.0 Volatile Organic Compound Certification RoHS compliant Eyesafe Certified 2.0 TÜV Rheinland Eye Comfort Certification TÜV Rheinland Low Blue Light (Hardware Solution)
