- Brand : Lenovo
- Product family : ThinkVision
- Product name : E27q-20
- Product code : 62D0GAT1UA
- GTIN (EAN/UPC) : 0195713989855
- Category : Computer Monitors ✚
- Data-sheet quality : created/standardized by Icecat
- Product views : 1309
- Info modified on : 02 Jun 2025 09:31:46
- EU Energy Label 0.1MB Product Brochure/Datasheet (4.3 MB) EU data-sheet (0.1 MB) ThinkVision E27q-20 Simplified service manual for dismantling (0.9 MB) User Guide (4.0 MB) Quick Start Guide (13.1 MB) Health Administration (0.5 MB) Compliance Statement (1.0 MB) EU data-sheet (0.1 MB)
Embed the product datasheet into your content.
| Display | |
|---|---|
| Display diagonal | 68.6 cm (27") |
| Display resolution | 2560 x 1440 pixels |
| HD type | Quad HD |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Panel type | IPS |
| Backlight type | W-LED |
| Touchscreen | |
| Display brightness (typical) | 350 cd/m² |
| Response time | 6 ms |
| Anti-glare screen | |
| Screen shape | Flat |
| Contrast ratio (typical) | 1000:1 |
| Contrast ratio (dynamic) | 3000000:1 |
| Maximum refresh rate | 75 Hz |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display colors | 16.7 million colours |
| Response time (fast) | 4 ms |
| Pixel pitch | 0.233 x 0.233 mm |
| Pixel density | 108 ppi |
| Viewable size, horizontal | 59.7 cm |
| Viewable size, vertical | 33.6 cm |
| Colour depth | 8 bit |
| Colour gamut standard | sRGB |
| Color gamut | 99% |
| Performance | |
|---|---|
| Flicker-free technology | |
| Low Blue Light technology | |
| Multimedia | |
|---|---|
| Number of speakers | 2 |
| RMS rated power | 4 W |
| Built-in speaker(s) | |
| Built-in microphone | |
| Built-in camera | |
| Design | |
|---|---|
| Product colour | Black |
| Color name | Raven Black |
| Feet colour | Black |
| Ports & interfaces | |
|---|---|
| Built-in USB hub | |
| HDMI | |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.2 |
| Audio output | |
| Ergonomics | |
|---|---|
| VESA mounting | |
| Ergonomics | |
|---|---|
| VESA mounting interfaces | 100 x 100 mm |
| Cable lock slot | |
| Cable lock slot type | Kensington |
| Height adjustment | |
| Adjustable height (max) | 15.5 cm |
| Pivot | |
| Pivot angle | -90 - 90° |
| Swivelling | |
| Swivel angle range | 0 - 360° |
| Tilt adjustment | |
| Tilt angle range | -5 - 22° |
| On Screen Display (OSD) | |
| Power | |
|---|---|
| Energy efficiency class (SDR) | F |
| Energy consumption (SDR) per 1000 hours | 26 kWh |
| Power consumption (typical) | 30 W |
| Power consumption (max) | 40 W |
| Power consumption (off) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply type | Internal |
| Energy efficiency scale | A to G |
| Weight & dimensions | |
|---|---|
| Width (with stand) | 613.6 mm |
| Depth (with stand) | 220 mm |
| Height (with stand) | 574 mm |
| Weight (with stand) | 6.6 kg |
| Width (without stand) | 613.6 mm |
| Depth (without stand) | 46.2 mm |
| Height (without stand) | 367.6 mm |
| Weight (without stand) | 4.5 kg |
| Bezel width (side) | 2 mm |
| Bezel width (top) | 2 mm |
| Bezel width (bottom) | 2.2 cm |
| Packaging data | |
|---|---|
| Package width | 730 mm |
| Package depth | 186 mm |
| Package height | 460 mm |
| Package weight | 9 kg |
| Packaging content | |
|---|---|
| Stand included | |
| Cables included | HDMI, Power |
| Quick start guide | |
| HDMI cable length | 1.8 m |
| Power cable length | 1.8 m |
| Other features | |
|---|---|
| Certification | ENERGY STAR CCC EPEAT Silver RoHS |
